PS3H122R (Nikon) Motorized Focus Drive
Bolt-On Focus Drive for Nikon Microscopes
Prior’s PS3H122R bolt-on motorized focus drive is compatible with manual Nikon microscopes. See the product compatibility tab for details.
The unit clamps directly to the coarse focus knob and assumes control over the fine focus, having sufficient resolution to maintain the step resolution of the manual focus drive it is attached to.
Installation is simple and does not require the microscope body to be inverted or disassembled. Simply clamp the PS3H122R onto the focus drive and push it onto the fine focus knob. Additionally, some microscopes allow the PS3H122R to be directly coupled to the fine focus drive, enhancing repeatability.
Compatible with Prior’s 3-axis OptiScan® and ProScan® controllers, the PS3H122R represents a simple method of enabling automated Z-stacking, extended focus and autofocus operations on manual microscopes.
The PS3H122R is compatible with Nikon NIS Elements software (appropriate package required).
- No twist cable connection
- 0.002 µm minimum step size ensures microscope fine focus resolution is retained
- Easy to install, no microscope disassembly required
- Adaptable to numerous current and older generation Nikon microscopes
- Compatible with Prior OptiScan and ProScan controllers
| Resolution | 0.002 µm |
|---|---|
| Maximum load | 15 kg |
| Travel range | ∞ |
| Cable length | 2 m |
Contact us for accessories information.
PS3H122R_Datasheet.pdf
Nikon-EN-US-Sales-Guide.pdf
PS3H122R_SAMPLE_CAD.zip
| Option | Manufacturer | Compatibility | Notes |
|---|---|---|---|
| PS3H122R+ H2975 | Nikon | Ti-U, Ti2-U, Ti2-A, Ts2R | |
| PS3H122R+ H2531+ H122KNI | Nikon | 50i, 80i, 90i | Direct Coupling |
| PS3H122R+ H3273 | Nikon | MA200 | |
| PS3H122R+ H3940+ H122KNI | Nikon | Ni-U, Ni-L | Direct Coupling |
| PS3H122R+ H3909 | Nikon | LV100ND, LV100NDA, LV150N, LV150NA | |
| PS3H122R+ H550 | Nikon | FN1 | |
| PS3H122R+ H3940+ H122KNC | Nikon | Ci-E, Ci-L, Ci-S | Direct Coupling |
| PS3H122R+ H2975+ H122KTI2 | Nikon | Ti2-U, Ti2-A, Ts2R | Direct Coupling |
| PS3H122R+ H2975+ H122KN2K | Nikon | Ti-U | Direct Coupling |
