ProScan H101A (Evident) Motorized XY Stage
High Speed Microscope Automation for Evident/Olympus BX and SZX Upright Microscopes (114 mm x 75 mm travel)
The ProScan H101BX is a motorized XY stage for Evident/Olympus upright microscopes.
It has a 2 mm ballscrew and 200-step motor for a balance of speed and resolution, offering sub-micron repeatability while also providing 4 times the speed of the H1P4A stage. The encoded HE01BX version also uses linear encoders for long-range repeatability. Prior’s patented Intelligent Scanning Technology (IST) optimizes stage accuracy, linearity, and repeatability.
The H101BX accommodates a variety of specimen types including glass slides, multiwell plates, semiconductor wafers, and metallurgical samples.
This stage is compatible with Evident/Olympus CellSens Dimension, Stream Motion, and PRECiV software (appropriate package required).
See the product compatibility tab for the full list of options available.
This is an ‘OEM & Batch Order’ product. For more information visit our FAQs section.
- Compatible with Evident upright microscopes
- 1µm or better repeatability
- Quiet and reliable
- Wide range of sample holders
- Intelligent Scanning Technology™ (US Patent 7,330,307)
| Travel range | 114 mm x 75 mm |
|---|---|
| Unidirectional repeatability | < 0.6 µm |
| Bidirectional repeatability | < 2.9 µm |
| Metric accuracy | 0.12 µm/mm |
| Full travel metric accuracy | < 12.0 µm |
| Resolution | 0.04 µm |
| Squareness | < 30 arcsec |
| Maximum velocity | 60 mm/s |
| Maximum load | 10 kg |
| Encoders | No |
| Motor type | 200 step |
| Screw pitch | 2 mm |
| Weight | 3.5 kg |
| Travel range | 114 mm x 75 mm |
| Unidirectional repeatability | < 0.6 µm |
| Bidirectional repeatability | < 1.0 µm |
| Metric accuracy | 0.11 µm/mm |
| Full travel metric accuracy | < 9.0 µm |
| Resolution | 0.1 µm |
| Squareness | < 30 arcsec |
| Maximum velocity | 60 mm/s |
| Maximum load | 10 kg |
| Encoders | 0.1 µm linear encoders |
| Motor type | 200 step |
| Screw pitch | 2 mm |
| Weight | 3.5 kg |
- H230 Aluminum plate.
- H220 Glass plate (not suitable for transmitted light microscopy).
- H473UP Universal specimen holder (slides, Petri dishes and small flasks) for stereo microscopes
- H649 Holder for a single 1 in, 1.25 in and 1.5 in mounted metallurgical specimen
- H224LP Low profile slide holder for one 76×26 mm microscope slide.
H101A-EN-Datasheet.pdf
Evident-Olympus-EN-US-Sales-Guide.pdf
H101A_REFERENCE-PART-NONAMES.zip
H101A_REFERENCE-IGES.zip
H1P4A-REFERENCE-PART-NONAMES.zip
H1P4A-REFERENCE-IGES.zip
HEP4A-REFERENCE-IGES.zip
| Option | Manufacturer | Compatibility | Notes |
|---|---|---|---|
| H101BX | Evident/Olympus | BX51, BX61, BX53, BX53M, SZX Series | SZX series requires STAD-2 adapter |
| H101BXWI | Evident/Olympus | BX51WI, BX61WI | |
| HE01BX | Evident/Olympus | BX51, BX61, BX53, BX53M, SZX Series | SZX series requires STAD-2 adapter |
